Hydraulic Toplink
Heavy Type With Hook
Stock Number
CTP320024
Add To Basket
Product varieties
Contrapart NoClosed Length L (mm)Open Length (mm)Stroke (mm)Tube Dia (D)Rod Dia (d)C (mm)N (mm)Impulse/Pull Force ( Tonne) Transaction
CTP320024500685185Ø70 X Ø80Ø45Ø26476,5 / 5,4
CTP320025550785235Ø70 X Ø80Ø45Ø26476,5 / 5,4
CTP320026600885285Ø70 X Ø80Ø45Ø26476,5 / 5,4
CTP3200276801035355Ø70 X Ø80Ø45Ø26476,5 / 5,4
